Topic 2: Area and Perimeter – Basic Mathematics Form Four

Area of any Triangle

The Formula for the Area of any Triangle

Derive the formula for the area of any triangle

Area of triangle is given by½bh, whereby b is the base of the triangle and h is the height of the given triangle. Consider the illustrations below:

040523 1524 TOPIC2AREAA1

From the figure above, we see where the base and height are located.

Applying the Formula to find the Area of any Triangle

Apply the formula to find the area of any triangle

Example 1

The base of a triangle is 12cm long. If the corresponding height is 7cm, find the area of the triangle.

Solution

Consider the figure below:

040523 1524 TOPIC2AREAA2

The area of a triangle is given by½bh.

Area =½×12cm×7cm

Area = 42cm2

Therefore area of a triangle is 42cm2

Example 2

The lengths of two sides of a triangle are 6cm and 8cm. Find the area of a triangle if the included is

Solution:

Consider the triangle below, name it triangle ABC.

040523 1524 TOPIC2AREAA3

The area of a triangle above is given by½b×h

So, Area = ½× 8cm× 6cm × sin 45°

=24cm2× sin45°

= 16.97cm2

Therefore the area of ABC = 16.97cm2

Area of a Rhombus

The Formula for Finding the Area of Rhombi in Terms of the Diagonals

Derive the formula for finding the area of rhombi in terms of the diagonals.

The area of a rhombus is the same as the area of a parallelogram because rhombus is a special kind of parallelogram. Rhombus is a parallelogram with equal sides. Consider the figure below of a rhombus with base b and height h.

040523 1524 TOPIC2AREAA4

So, Area of rhombus = bh

Another formula for finding the area of rhombus can be obtained by using the diagonals. Consider the rhombus below:

040523 1524 TOPIC2AREAA5

Diagonals of a rhombus bisect each other at right angles (means the diagonal lines are half equally), so the area of a rhombus ABCD can be found as follows:

Area of a triangle ABC = area of a triangle ADC

040523 1524 TOPIC2AREAA6

Since the triangles are equal, the area of ABCD:

040523 1524 TOPIC2AREAA7

Therefore, the area of a rhombus is equal to half the product of the length of the diagonals.

The Formula to Find the Areas of Quadrilaterals

Apply the formula to find the areas of quadrilaterals

Area of a Trapezium

Consider the trapezium with constructed lines as shown in the figure below:

040523 1524 TOPIC2AREAA8

In order to find the area of a trapezium, first let us find the area of the triangles ABD and BDF with the same height h.

The base of the triangle ABD is b1

The base of the triangle BDF is b2

The area of the triangle ABD = ½b1h

The area of the triangle ABE = ½b1h

Area of ABDF =½b1h +½b2h

Area of ABDF=½ (b1 + b2)h

Generally, the area of the trapezium is given by½ (b1+ b2)hor is the product of half the sum of the parallel sides (bases) and the perpendicular distance between them (height)

Example 3

Find the height of the trapezium with area 90 square units and bases of 6 units and 14 units

Solution:

Consider the trapezium below:

040523 1524 TOPIC2AREAA9

Therefore the height of the trapezium is 9 units.

Area of a Parallelogram

Consider parallelogram below with constructed lines as shown in the figure.

040523 1524 TOPIC2AREAA10

The area of the parallelogram can be formed from the formula for the area of the trapezium. The important thing to note is that the bases for a parallelogram are equal.

Now, the area of the parallelogram ABCD=½ (AB+DC)hsquare units.Since AB = DC

Then, the area of parallelogram ABCD =½ × 2AB × h = AB× h

If AB =b, then Area of the parallelogram ABCD = bh, where b is the base and h is the height of a parallelogram.

Therefore; the area of a parallelogram is equal to the product of the base and the perpendicular height.

Area of a Rectangle

Consider the rectangle below:

040523 1524 TOPIC2AREAA11

The rectangle ABCD is divided into two congruent triangles, which are triangle ABD and triangle ACD by the diagonal AD.

The area of ABCD = area of triangle ABD + area of triangle ACD

040523 1524 TOPIC2AREAA12

Since the triangles are equal, the area of ABCD is equals to double the area of one of the triangles.The area of ABCD

040523 1524 TOPIC2AREAA13

If CD is the length ‘l’of the Rectangle and AC is the width ‘w‘ of the Rectangle, then, the area of ABCD = l×w or lw

Therefore, the area of the Rectangle is the product of the length and width.

Area of a Square

A Square is a special rectangle with equal sides. Therefore the area of the square is the product of its lengths. i.e. Area of a square = l × l=l2.

We can also find the area of a square by using the length of the diagonals. Consider the square below with diagonals AC and DB:

040523 1524 TOPIC2AREAA14

Each of the diagonals of a square bisect at a right angle.Area of a triangle ABC = Area of ADC

040523 1524 TOPIC2AREAA15

But the area of ABCD

040523 1524 TOPIC2AREAA16

Since the length of the diagonals are equal, then AC = BD.So, the area of ABCD = ½ (AC)2

Therefore the area of a Square is equals to the half of the product of the lengths of the diagonals.

Example 4

Find the area of a parallelogram ABCD if AC = 7cm, AB = 9cm and the angle ZWX =.

040523 1524 TOPIC2AREAA17

Solution

Area of a parallelogram = base×height

Consider the figure below:

040523 1524 TOPIC2AREAA18

Consider the triangle ACE to find h

040523 1524 TOPIC2AREAA19

Therefore the area of the parallelogram ABCD is 53.427cm2.

Perimeter of a Regular Polygon

The Formula for Finding the Length of a Side of a Regular Polygon

Derive the formula for finding the length of a side of a regular polygon

When we sum up the lengths of the sides of the polygon we obtain what is called perimeter of a polygon. Therefore, perimeter of a regular polygon is the sum of the lengths of the sides of the polygon.

How to find the perimeter of a Regular Polygon inscribed in a circle?

An inscribed polygon is the one whose vertices lie on the circle. If the lengths of the sides of the polygon are the same we say that the polygon is an inscribed Regular Polygon.

A Regular Polygon with number of sides larger than 2 say n sides can be inscribed in a circle as follows:

For example, if you want to construct an inscribed regular hexagon (6 sides), first draw a circle and locate the center of the circle. Then draw rays that intersect the circle in six points from the center of the circle. Each angle at the center will measure 360°/6 = 60°. Connect the points of intersection on the circle by line segments. The figure formed is an inscribed regular polygon. See the figure below:

040523 1524 TOPIC2AREAA20

Now, to obtain the formula of finding the perimeter of a regular polygon inscribed in a circle with radius r and center O, let AB be the side of the polygon and OC the perpendicular from O to AB as shown in the figure below:

040523 1524 TOPIC2AREAA21

The angle AOB = 360°/n, since the polygon has n sides.

The angle AOC = the angle AOB and the angle AOB = angle AOC + BOC

Therefore, the angle AOC = ½(360°/n) = 180°/n

Let the length of the side of the regular polygon ABbe S.

Then,

040523 1524 TOPIC2AREAA22

Therefore the length of a regular polygon with n sides inscribed in a circle is given by

040523 1524 TOPIC2AREAA23

The Perimeter of a Regular Polygon

The formula to determine the perimeter of a regular polygon

If we let 2r = d

040523 1524 TOPIC2AREAA24

From the concept of perimeter that perimeter of a regular polygon is the sum of the lengths of the sides of the polygon , if we have n sides each with length ‘S’ then the sum of the lengths of these sides will be nS. Therefore, Perimeter P of a regular polygon of n sides each with length S is given by:

040523 1524 TOPIC2AREAA25

Example 5

Find the length of one side of eight-sided regular polygon inscribed in a circle with radius 7cm.

Solution

040523 1524 TOPIC2AREAA26

Therefore the length of one side of eight-sided regular polygon with radius of 7cm is 5.358cm

Area of a Regular Polygon

The Formula for Finding the Area of a Regular Polygon

Derive the formula for finding the area of a regular polygon

Consider the regular polygon with n sides inscribed in a circle of radius r and center O as shown below:

040523 1524 TOPIC2AREAA27

040523 1524 TOPIC2AREAA28

But since each vertex of the polygon is connected to O, the polygon region is divided into n triangles which are equal.

Now,

040523 1524 TOPIC2AREAA29

Therefore the area of a polygon of n sides inscribed in a circle of radius r is given by:

040523 1524 TOPIC2AREAA30

The Formula to Calculate the Area of a Regular Polygon

Apply the formula to calculate the area of a regular polygon

Example 6

Find the area of twelve-sided regular polygon inscribed in a circle of radius 14 cm

Solution

040523 1524 TOPIC2AREAA31

Circumference and area of a circle

Circumference of a circle is the distance around it. Circumference of a circle can be estimated by using a regular polygon with many sides inscribed in a circle with radius r.

We know perimeter of the regular polygon is given by:

040523 1524 TOPIC2AREAA32

Here we see that, as n increases the value of nsin 180°/napproaches the value ofπ.When n is very large the perimeter of a regular polygon approaches the circumference of the circle. The value ofnsin 180°/ncan be replaced byπbecause it approaches the value ofπwhen n is very large.

Therefore, circumference of the circle C, is given by C = 2πr

Area of a Circle

In similar way we can generate the formula of calculating the area of a circle by considering area of a regular polygon inscribed in a circle of radius r.

We know that, area of a regular polygon is given by:

040523 1524 TOPIC2AREAA33

Alternatively we can write it as:

040523 1524 TOPIC2AREAA34

040523 1524 TOPIC2AREAA35

Example 7

Find the circumference of a circle of radius 21cm. (takeπ= 3.14).

Solution

Circumference of a circle, C = 2πr

= 2× 3.14 × 21cm = 131.88cm

Area of Similar Polygons

The Ratio of Areas of Similar Polygons

Find the ratio of areas of similar polygons

Let ABC and A’ B’ C’ be two similar triangles:

040523 1524 TOPIC2AREAA36

Area and Perimeter

If we find the ratio of their sides we get;

040523 1524 TOPIC2AREAA37

Generally, if the ratio of the lengths of the corresponding sides of two similar polygons is k, then the ratio of their areas is k2.

Problems Related to Ratio for Areas of Similar Polygons

Solve problems related to ratio for areas of similar polygons

Example 8

We are given two triangles which are similar. The length of one side is 8cm and the length of the corresponding side is 14cm. if the area of a smaller triangle is 24cm2find the area of the other triangle.

Solution

040523 1524 TOPIC2AREAA38

Therefore the area of the other triangle is 73.5cm2.

Example 9

The ratio of the areas of two similar polygons is 36:48. The length of a side of the smaller polygon is 10cm. find the length of the corresponding side of the other polygon.

Solution

040523 1524 TOPIC2AREAA39
